Log File Reader

Discussion in 'Roadster' started by SuperB, May 12, 2009.

  1. SuperB

    SuperB Member

    Joined:
    Mar 16, 2009
    Messages:
    20
    Location:
    coral springs fl
    Anyone have info about how to read the log files created by the Tesla to the USB port?

  2. Picasso

    Picasso kllkkjlk

    Joined:
    May 8, 2009
    Messages:
    54
    #2 Picasso, May 12, 2009
    Last edited: May 12, 2009
    hmm

    Have you been able to download any? From what I understand just put in a USB stick with a DIR on it and it will put the logs on it. A few remote tesla roadster users have been sent info on how to pull the logs. If you could post or email one of the logs I will do my best to try and decode it.

    My wish is for Tesla to be open about all the controls in the car, This also includes allowing us to write our own firmware. Sure it would void the warrenty but Im ok with that.


    Also is a service menu you can access via the display, tap the screen 10 times to enter, need a code. Unsure if its tied to vin...thats the way Id do it. But I think the code is based on what firmware the car has.

    You can also talk to the differnt control systems in the car. It IP over can.


    Are you looking for errors with the A/C? You should get a temp probe stick it in the vent turn on on AC Full and check the temp. Report the temps you get on full at 2/5/10min mark and report to Tesla. From what I understand the AC is dumb and just turns on/off I don't think it will put any log fwd.

  3. SuperB

    SuperB Member

    Joined:
    Mar 16, 2009
    Messages:
    20
    Location:
    coral springs fl
    Yes, I created a log to send to Tesla.
    They put a .tar file on the USB device in a folder VehicleLogs, which must already exist. Pretty simple process.
    .tar files are just a type of file compression, I decompressed it and there are several files, most are not simple text files, so I can't read them. The text files don't have any meaningful info in them.

    The logs were created to diagnose my PEM running hot, not the AC.

  4. Picasso

    Picasso kllkkjlk

    Joined:
    May 8, 2009
    Messages:
    54
  5. johnr

    johnr Member

    Joined:
    Apr 14, 2009
    Messages:
    282
  6. Lennart

    Lennart Member

    Joined:
    Sep 18, 2009
    Messages:
    16
    Anyone found a way to read those files?

  7. raymond

    raymond Member

    Joined:
    Jan 14, 2008
    Messages:
    345
    Location:
    The Netherlands
    If anybody can give me a log file I'd be more than willing to give it a go.

  8. mowcow

    mowcow New Member

    Joined:
    Jan 7, 2010
    Messages:
    2
    #8 mowcow, Jan 7, 2010
    Last edited: Jan 8, 2010
    Code:
    Linux version 2.6.11.8-2.1.0
    LPC2294
    release : vehicle-firmware-4.1.21.23 : 4.1.21 : 4.1.21/ : 23 :

  9. scott451

    scott451 KWH-PWR#1349Sprt,S Sig#96

    Joined:
    Apr 2, 2009
    Messages:
    251
    Location:
    Palo Alto
    Yes. What were you looking for?

    -Scott

  10. scott451

    scott451 KWH-PWR#1349Sprt,S Sig#96

    Joined:
    Apr 2, 2009
    Messages:
    251
    Location:
    Palo Alto
    #10 scott451, Jan 7, 2010
    Last edited: Nov 18, 2010
    Log parsing

    Kind of a boring log file... Lots of stuff in there, but only 20.1 miles on the odometer. Max speed was:

    2009/sep/14 00:19:41 am, 29KW 79.5mph.

    A couple of recent errors:

    2009/Oct/12 23:54:37 Check left front turn signal bulb
    2009/Oct/12 23:54:38 Check left back turn signal bulb
    2009/Oct/13 00:53:57 Airbag must be serviced. Contact Tesla Service Center.

    This log must have been pulled very early, as I can see back to the birth of the car...

    -Scott

    PS my parser is based on the 2008 logs. The 2010 logs are different in a number of ways, especially wrt charging, they removed one type and added another. It will take a while to decypher the logs for the 2010 charge info...


    Attached Files:

  11. mowcow

    mowcow New Member

    Joined:
    Jan 7, 2010
    Messages:
    2
    hey scott451, gj!

    read please my pm. thanks!

  12. Neb

    Neb Member

    Joined:
    Oct 24, 2009
    Messages:
    44
    Location:
    Colorado
    Scott,

    Can you share your parser with us?

    Ben

  13. scott451

    scott451 KWH-PWR#1349Sprt,S Sig#96

    Joined:
    Apr 2, 2009
    Messages:
    251
    Location:
    Palo Alto
    #13 scott451, Jan 8, 2010
    Last edited: Nov 18, 2010
    I'm working on that... It will probably be web based, so you upload a logfile and it sends you the spreadsheet.

    My parser works pretty well with the Model yr 2008 log dumps, but the 2010 are different. So I'm working on getting those issues resolved. Anyone willing to send 2010 logs, send me a PM.

    -Scott

    PS for your records take a log dump every three months, and right before going in for service...

    [edit 11-18-2010: my log parser is now available. See attached file]


    Attached Files:

  14. Alpine Driver

    Alpine Driver Member

    Joined:
    Mar 24, 2008
    Messages:
    92
    Location:
    Austria
    Scott,

    very interesting thing.

    sent you PM. I would like to send a 2010 european logfile, so that this part is also covered.

    Hope it does not matter, since the last firmware upgrade (tesla technicians came by), the car is in storage mode and did not move a mile.

    best
    Martin

  15. doug

    doug Administrator / Head Moderator

    Joined:
    Nov 28, 2006
    Messages:
    16,088
    Interesting. Are you able to get battery temperature data from the logs? It seems to me that Tesla treats that data as proprietary or at least something that gives them a competitive advantage.

    Last fall JB gave a presentation at a CARB symposium and quickly showed a couple slides with battery temp data. However, when that presentation became available online, those particular slides were removed.

  16. scott451

    scott451 KWH-PWR#1349Sprt,S Sig#96

    Joined:
    Apr 2, 2009
    Messages:
    251
    Location:
    Palo Alto
    #16 scott451, Feb 13, 2010
    Last edited: Feb 13, 2010
    Yes and no. It apears that there at four temperature sensors per sheet (11 sheets total). So 44 temp sensors cover 99 bricks. the logs contain only min/max temp of 44 sensors. As far as I can tell, all of the sensors are not logged, only the min/max and possibly the average temp.

    Can you be more specific about the slides that were removed?

    Thanks,

    -Scott

  17. doug

    doug Administrator / Head Moderator

    Joined:
    Nov 28, 2006
    Messages:
    16,088
    Umm... I can't quite remember. I wasn't physically there. I was watching live online and no recording is available.

  18. pentest317

    pentest317 New Member

    Joined:
    Jun 30, 2017
    Messages:
    2
    Location:
    VietNam
    Please send me your code in log_parse.exe file. I want to edit something in this. Thanks :)

    • Disagree x 1
  19. Roadster

    Roadster Member

    Joined:
    Dec 10, 2016
    Messages:
    312
    Location:
    SoCal
    [​IMG]

    • Like x 1
    • Funny x 1
  20. wiztecy

    wiztecy Active Member

    Joined:
    Apr 29, 2012
    Messages:
    2,880
    Location:
    Santa Cruz, California, United States
    I agree with the pic above. Two things to point out, first explain why you want the code. You said you want to 'edit something". What is this 'something'? Roadster owners have been using this app for quite some time without any issue. Secondly, looking at your post you only have 2 posts, so that's a bit concerning since we really don't know who you are or what you're doing with the code, or even if you have a Roadster. I looked up the other post of yours, and its just plain old nonsense! This is pretty much about what you said, "aaaaaaaaaa". So with that, nobody is going to take you seriously. And from my impression you look like a spammer who just wants to stick malware inside a very good app the community uses. If it was me I'd be like, let me thing about this.... Um, no. Lastly, you do see how old the inactivity of what this thread was.... right? Its over 7 years, so chances that the original code holder is still on this site, which it can be possible, is very slim. And that's the case. He's no longer here. Its like going to an abandoned house since you ran out of milk and asking if they have any. I suggest in the future being part of the community and adding to it before making some odd request.

    Screen Shot 2017-07-01 at 8.17.35 AM.png

    • Like x 6
